60A 12V/24V DC Auto MPPT Solar Charge Controller Common Negative Ground Parameter Adjustable LCD Display Solar Panel Regulator fit for Gel Sealed Flooded Lithium Battery

GCSOAR MPPT Solar Charge Controller 60A 12V/24V Auto Work Max 100V PV Solar Panel Charger Common Positive Grounding, Auto control system to limit the charging power & current under the rated value ★Max Input Current: 60 amp: Max Input Solar Power: 780W/12V 1560W/24V; Real-time energy recording and statistical. ★Support Sealed(SEL), Gel(GEL), Flooded(FLD), User-defined(USE) batteries and Lithium(Lit) Batteries too, Battery temperature compensation function to ensure the battery’s life. ★RS-485 communication bus interface and Modbus communication protocol, available to meet various communication requirements in different situations. ★MPPT Solar controller 60A with Dual RS485 communication, suppoprt parallel two/three or more controller to make 120A/180A system. Technical Data: Nominal system voltage:12V/24V DC auto identify Rated charging current :60A Rate discharging/Load current:30A Battery Type: Lead-acid(sealed/Flooded/Gel) and Lithium(LiFePO4, Li-NiCoMn) and User. Dual RS485 communication, suppoprt parallel two/three or more controller to make 120A/180A system. Max. PV open circuit voltage:100V MPPT technology tracking efficiency>=99.5%, conversion efficiency>98% Max. PV input power: 780W/12V, 1560W/24V Recommended Max cable: 28mm2 Operating ambient temperature: -20°C -- +50°C Dimension:245*170*63.5mm weight :2.35 KG Package List: 1 X MPPT Solar Charge Controller 60A 1 xTemp sensor cable 1 x Setting Instructions(English) 1X Manual (English)

• GCSOAR MPPT solar charge controller 60A with Temp sensor cable, 12V/24V Auto identifying system voltage, Max. PV(Voc) 100V, Solar Panels Max input power 780W/1560W Charging for 12V/24V battery system, MPPT efficiency can reach 99.5% or above, and peak conversion efficiency is up to 98%
• Support Sealed(SEL), Gel(GEL), Flooded(FLD), User-defined(USE) batteries and Lithium(Lit): LiFePO4, Li[NiCoMn]O2 Batteries too . Battery temperature compensation function to ensure the battery’s life. Multiple Powerful electronic protection against reverse polarity, overcharging, over-discharging, overloading, battery-shedding, short-circuiting, and reverse current is here for its safe operation
• Dual RJ45 port design/RS485 protocol allow you parallel Multiple controllers and meantime know each controller's working detail status and para. Parallel two or three...controllers can make 120A or 180A controller system. Support PC software & APP monitoring setting parameters , users can monitor and adjust solar system from home wifi to internet
• LCD-Display with high-definition provides PV input & DC load output information, battery information, charging dynamic &working states display, date & fault code display. A finger-touch interface is super convenient for users to operate freely. Ideal for solar off-grid system of telecommunication base station, household system, street lighting system, field monitoring system, etc.
